工作介质
|
内径(mm) |
12 |
16 |
20 |
25 |
32 |
40 |
50 |
63 |
80 |
100 |
|
|
工作介质 |
空气 |
||||||||||
|
动作型式 |
复动型 |
||||||||||
|
保证耐压力 |
1.5Mpa(15.3kgf/cm2) |
||||||||||
|
最高使用压力 |
1.0Mpa(10.2kgf/cm2) |
||||||||||
|
最低工作压力 |
0.12Mpa(1.2kgf/cm2) |
||||||||||
|
环境和流体温度 |
-10~+60℃ |
||||||||||
|
活塞速度 |
50~500mm/s |
50~400mm/s |
|||||||||
|
缓冲 |
橡胶缓冲 |
||||||||||
|
行准公程 |
+1.5 |
||||||||||
|
轴承 |
滑动轴承/滚珠导向轴承 |
||||||||||
|
活塞杆不转动精度 |
滑动轴承 |
±0.08° |
±0.07° |
±0.06° |
±0.05° |
±0.04° |
|||||
|
滚珠导向轴承 |
±0.10° |
±0.09° |
±0.08° |
±0.06 |
±0.05° |
||||||
|
接管口径 |
M5×0.8 |
G1/8" |
G1/4" |
G3/8" |
|||||||
|
缸径 |
标准行程 (mm) |
B |
C |
DA |
FA |
FB |
G |
GA |
GB |
H
|
HA |
J |
K |
L |
MM |
ML |
NN |
OA |
|
12 |
10 20 30 40 50 75 100 |
42 |
29 |
6 |
8 |
5 |
26 |
11 |
7.5 |
58
|
M4 |
13 |
13 |
18 |
M4×0.7 |
10 |
M4×0.7 |
4.3 |
|
16 |
46 |
33 |
8 |
8 |
5 |
30 |
11 |
8 |
64
|
M4 |
15 |
15 |
22 |
M5×0.8 |
12 |
M5×0.8 |
4.3 |
|
|
20 |
20 30 40 50 75 100 125 150 175 200
|
53 |
37 |
10 |
10 |
6 |
36 |
10.5 |
8.5 |
83
|
M5 |
18 |
18 |
24 |
M5×0.8 |
13 |
M5×0.8 |
5.6 |
|
25 |
53.5 |
37.5 |
12 |
10 |
6 |
42 |
11.5 |
9 |
93
|
M5 |
21 |
21 |
30 |
M6×1.0 |
15 |
M6×1.0 |
5.6 |
|
缸径 |
标准行程 (mm) |
OB |
OL |
P |
PA |
PB |
PW
|
Q |
R |
S |
T
|
U |
VA |
VB |
X |
XA |
XB |
XC |
YL |
Z |
|
12 |
10 20 30 40 50 75 100 |
8 |
4.5 |
M5×0.8 |
13 |
8 |
18
|
14 |
48 |
22 |
56
|
41 |
50 |
37 |
23 |
3 |
3.5 |
3 |
10 |
5 |
|
16 |
8 |
4.5 |
M5×0.8 |
15 |
10 |
19
|
16 |
54 |
25 |
62
|
46 |
56 |
38 |
24 |
3 |
3.5 |
3 |
10 |
5 |
|
|
20 |
20 30 40 50 75 100 125 150 175 200
|
9.5 |
5.5 |
RC1/8 |
12.5 |
10.5 |
25
|
18 |
70 |
30 |
81
|
54 |
72 |
44 |
28 |
3 |
3.5 |
3 |
12 |
17 |
|
25 |
9.5 |
5.5 |
RC1/8 |
12.5 |
13.5 |
28.5
|
26 |
78 |
38 |
91
|
64 |
82 |
50 |
34 |
4 |
4.5 |
3 |
12 |
17 |
|
缸径 |
标准行程 (mm) |
WA |
WB |
XL |
YY |
||||
|
30 st or less
|
Over 40 st to 100 st
|
125 st or less
|
30 st or less
|
Over 40 st to 100 st
|
125 st or less
|
||||
|
12 |
10 20 30 40 50 75 100 |
20 |
40 |
- |
15 |
25 |
-
|
6 |
M5×0.8 |
|
16 |
24 |
44 |
- |
17 |
27 |
-
|
6 |
M5×0.8 |
|
|
20 |
20 30 40 50 75 100 125 150 175 200
|
24 |
44 |
120 |
29 |
39 |
77
|
6 |
M6×1.0 |
|
25 |
24 |
44 |
120 |
29 |
39 |
77
|
6 |
M6×1.0 |
|
|
MGPG Slide bearing
|
MGPL Ball bushing bearing
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
MGPM Slide bearing
|
MGPL Ball bushing bearing
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
缸径 |
标准行程 (mm) |
B |
C |
DA |
FA |
FB |
G |
GA |
GB |
GC
|
H |
HA |
J |
K |
L |
MM |
ML |
NN |
OA |
OB |
OL |
P |
PA |
PB |
PW |
Q |
|
32 |
25,50, |
59.5 |
37.5 |
16 |
12 |
10 |
48 |
12.5 |
9 |
12.5
|
112 |
M6 |
24 |
24 |
34 |
M8×1.25 |
20 |
M8×1.25 |
6.6 |
11 |
7.5 |
RC1/8 |
7 |
15 |
34 |
30 |
|
40 |
66 |
44 |
16 |
12 |
10 |
54 |
14 |
10 |
14
|
120 |
M6 |
27 |
27 |
40 |
M8×1.25 |
20 |
M8×1.25 |
6.6 |
11 |
7.5 |
RC1/8 |
13 |
18 |
38 |
30 |
|
|
50 |
72 |
44 |
20 |
16 |
12 |
64 |
14 |
11 |
12
|
148 |
M8 |
32 |
32 |
46 |
M10×1.5 |
22 |
M10×1.5 |
8.6 |
14 |
9 |
RC1/4 |
9 |
21.5 |
47 |
40 |
|
|
63 |
77 |
49 |
20 |
16 |
12 |
78 |
16.5 |
13.5 |
16.5
|
162 |
M10 |
39 |
39 |
58 |
M10×1.5 |
22 |
M10×1.5 |
8.6 |
14 |
9 |
RC1/4 |
14 |
28 |
55 |
50 |
|
R |
S |
T |
U |
VA |
VB |
X |
XA |
XB |
XC |
XL |
Z |
|
96 |
44 |
110 |
78 |
98 |
63 |
42 |
4 |
4.5 |
3 |
6 |
21 |
|
104 |
44 |
118 |
85 |
106 |
72 |
50 |
4 |
4.5 |
3 |
6 |
22 |
|
130 |
60 |
146 |
110 |
130 |
92 |
66 |
5 |
6 |
4 |
8 |
24 |
|
130 |
70 |
158 |
124 |
142 |
110 |
80 |
5 |
6 |
4 |
8 |
24 |
MGPM Slide bearing
|
缸径 |
A |
DB |
E |
||||
|
50st≥ |
50st＜200st≥ |
200st＜ |
50st≥ |
50st＜200st≥ |
200st＜ |
||
|
32 |
97 |
102 |
140 |
20 |
37.5 |
42.5 |
80.5 |
|
40 |
97 |
102 |
140 |
20 |
31 |
36 |
74 |
|
50 |
106.5 |
118 |
161 |
25 |
34.5 |
46 |
89 |
|
63 |
106.5 |
118 |
161 |
25 |
29.5 |
41 |
84 |
MGPL Ball bushing bearing
|
缸径 |
A |
DB |
E |
||||||
|
50st≥ |
50st＜100st≥ |
100st＜200st≥ |
200st＜ |
50st≥ |
50st＜100st≥ |
100st＜200st≥ |
200st＜ |
||
|
32 |
81 |
98 |
118 |
140 |
16 |
21.5 |
38.5 |
58.5 |
80 |
|
40 |
81 |
98 |
118 |
140 |
16 |
15 |
32 |
52 |
74 |
|
50 |
93 |
114 |
134 |
161 |
20 |
21 |
42 |
62 |
89 |
|
63 |
93 |
114 |
134 |
161 |
20 |
16 |
37 |
57 |
84 |
|
缸径 |
标准行程 (mm) |
B |
C |
DA |
FA |
FB |
G |
GA |
GB |
GC |
H |
HA |
J |
LA
|
LB
|
K |
L |
MM |
ML |
NN |
OA |
OB |
OL |
P |
PA |
PB |
|
80 |
25,50,70, 100, |
95.5 |
56.5 |
25 |
22 |
18 |
91.5 |
19 |
15.5 |
14.5 |
202 |
M12 |
45.5 |
38
|
7.5
|
46 |
54 |
M12×1.75 |
30 |
M12×1.75 |
10.6 |
17.5 |
8 |
RC3/8 |
14.5 |
25.5 |
|
100 |
116 |
66 |
30 |
25 |
111.5 |
23 |
23 |
19 |
18
|
240 |
M14 |
55.5 |
45
|
10.5
|
56 |
62 |
M14×2.0 |
32 |
M14×2.0 |
12.5 |
20 |
8 |
RC3/8 |
17.5 |
32.5 |
|
缸径 |
标准行程 (mm) |
PW |
Q |
R |
S |
T
|
U
|
VA |
VB |
WA |
WB |
X |
XA |
XB |
XC |
XL |
YY |
YL |
Z |
||||
|
25st
|
50,75,100st
|
100st or above
|
25st
|
50,75,100st
|
100st or above
|
||||||||||||||||||
|
80 |
25,50,70, 100, |
74 |
52 |
174 |
75 |
198
|
156
|
180 |
140 |
28 |
52 |
128 |
42 |
54 |
92 |
100 |
6 |
7 |
5 |
10 |
M12×1.75 |
24 |
28 |
|
100 |
89 |
64 |
210 |
90 |
236
|
188
|
210 |
166 |
48 |
72 |
148 |
35 |
47 |
85 |
124 |
6 |
7 |
5 |
10 |
M14×2.0 |
28 |
11 |
|
|
缸径 |
A |
DB |
E |
||||
|
50st≥ |
50st＜200st≥ |
200st＜ |
50st≥ |
50st＜200st≥ |
200st＜ |
||
|
80 |
115 |
142 |
193 |
30 |
18.5 |
45.5 |
96.5 |
|
100 |
137 |
162 |
203 |
36 |
21 |
46 |
87 |
|
缸径 |
A |
DB |
E |
||||||
|
50st≥ |
25st＜50st≥ |
50st＜200st≥ |
200st＜ |
50st≥ |
25st＜50st≥ |
50st＜200st≥ |
200st＜ |
||
|
80 |
109.5 |
130 |
160 |
193 |
25 |
13 |
33.5 |
63.5 |
96.5 |
|
100 |
121 |
147 |
180 |
203 |
30 |
5 |
31 |
64 |
87 |
